Swiss CNC Turning Parts for Electronic Detector Applications

Swiss CNC Turning Parts for Electronic Detector Applications

electronic swiss cnc

electronic cnc swiss turning

brass swiss cnc

Place of Origin:

China

Brand Name:

YS Precision

Certification:

ISO9001

Model Number:

Swiss-Type CNC Turning parts

CONTACT US
Request A Quote
Product Details
Application:
Electronic Detector Components
Part Name:
Brass Heater Stand
Customer Market:
Global Electronics Industry
Quantity:
30,000 Pcs
Material:
Brass
Manufacturing Process:
Swiss-Type CNC Turning
Part Size:
Ø1.9mm × 5mm
Critical Tolerance:
±0.01mm
Surface Treatment:
0.5μm Gold Plating
Production Stage:
Volume Manufacturing
Highlight:

electronic swiss cnc

,

electronic cnc swiss turning

,

brass swiss cnc

Payment & Shipping Terms
Minimum Order Quantity
Negotiable
Price
Negotiable
Packaging Details
EPE Foam Inside And Carton Outside Or EPE Foam Inside And Wooden Outside
Delivery Time
3-7 Days For Sample Order, 10-15 Days For Bulk Order After, Depend On The Part Structure And Size
Payment Terms
T/T
Supply Ability
5000 Piece/Month
Product Description

Swiss CNC Turning Parts for Electronic Detector Applications

Reliable High-Precision Manufacturing of Miniature Brass Components for Volume Production

From Customer Drawings to Stable Production of Critical Electronic Parts






Project Background

A global electronics manufacturer required a reliable manufacturing partner to produce miniature brass heater stands used in electronic detector assemblies.
Although the component size was extremely small, it was a critical functional part inside the electronic system.
The customer required a supplier capable of delivering:

  • Stable production quality
  • Consistent dimensional accuracy
  • Reliable surface treatment
  • Long-term manufacturing capability

The components were manufactured according to customer-provided:

  • 2D engineering drawings
  • 3D CAD models

The production requirement reached:
30,000 pieces
YS Precision provided a complete manufacturing solution, including:

  • Engineering review
  • Swiss-type CNC turning
  • Precision inspection
  • Gold plating
  • Production management

to deliver reliable miniature precision components.





Project Overview

Item Details
Application Electronic Detector Components
Part Name Brass Heater Stand
Customer Market Global Electronics Industry
Quantity 30,000 pcs
Material Brass
Manufacturing Process Swiss-Type CNC Turning
Part Size Ø1.9mm × 5mm
Critical Tolerance ±0.01mm
Surface Treatment 0.5μm Gold Plating
Production Stage Volume Manufacturing






Customer Challenge

Finding a Manufacturing Partner for Ultra-Small Precision Components

For electronic equipment manufacturers, small precision components often have a significant impact on final product reliability.
The customer faced several challenges:





1. Extremely Small Component Size

The heater stand dimensions were:

  • Maximum diameter: Ø1.9mm
  • Length: 5mm

Such miniature parts require:

  • Stable machining conditions
  • Accurate tooling control
  • Professional small-part manufacturing experience






2. High Production Consistency

The requirement was: 30,000 pieces
The challenge was not producing one good sample, but ensuring every batch maintained:

  • Same dimensions
  • Same surface quality
  • Same assembly performance






3. Functional Gold Plating Requirement

The component required: 0.5μm real gold plating
The surface finish needed to provide:

  • Stable electrical performance
  • Corrosion resistance
  • Reliable contact performance

Machining quality and surface treatment quality both directly affected final product reliability.





YS Precision Manufacturing Solution

Complete Supply Chain Management from Machining to Surface Treatment

Instead of only providing machining, YS Precision managed the complete manufacturing process.
The solution included:

Precision Swiss CNC Turning

For miniature brass component manufacturing.

Quality Control

For critical dimensions and production consistency.

Gold Plating Management

To achieve the required functional surface performance.
This integrated approach reduced supplier coordination risks for the customer.





Why Swiss CNC Turning Was Selected

Ideal Technology for Miniature Precision Production

Swiss CNC turning is specifically designed for:

  • Small diameter components
  • High precision requirements
  • Long-term production stability

Compared with conventional turning methods, Swiss machining provides:





Better Machining Stability

The guide bushing system supports the material close to the cutting area.
Benefits:

  • Reduced vibration
  • Improved dimensional stability
  • Better surface quality






Excellent Repeatability

For 30,000-piece production, repeatability is critical.
Swiss CNC turning helps maintain:

  • Consistent dimensions
  • Stable process performance
  • Reliable production output






Efficient Production Process

Multiple operations can be integrated:

  • Turning
  • Grooving
  • Chamfering
  • Precision forming

Reducing secondary handling and improving consistency.





Manufacturing Process

1. Engineering Review

After receiving the customer's 2D drawings and 3D models, YS Precision reviewed:

  • Part structure
  • Critical dimensions
  • Machining feasibility
  • Material characteristics
  • Surface treatment requirements






2. Swiss-Type CNC Turning Production

The brass heater stands were manufactured using precision Swiss CNC turning machines.
Production control focused on:

  • Tool condition management
  • Process stability
  • Dimensional repeatability






3. Precision Quality Inspection

Quality control included:

First Article Inspection

Verification before mass production.

In-Process Inspection

Monitoring critical dimensions during production.

Final Inspection

Confirming finished parts before shipment.
Key inspection items:

  • Diameter accuracy
  • Length dimensions
  • Critical tolerance requirements
  • Surface appearance






4. Gold Plating Process

After machining, the components received:
0.5μm gold plating
The coating provided:

  • Functional surface performance
  • Corrosion resistance
  • Improved reliability in electronic applications






Project Result

YS Precision successfully delivered:
30,000 brass heater stands
for electronic detector applications.
The customer received:
✓ Stable volume production capability
✓ Consistent precision components
✓ Controlled ±0.01mm critical dimensions
✓ Reliable gold-plated surfaces
✓ Reduced supplier management complexity
The project demonstrated YS Precision's ability to support customers requiring miniature precision components with demanding quality and production requirements.





Why Global Electronics Companies Choose YS Precision

For critical electronic components, choosing the right manufacturing partner is not only about machining capability.
Customers need:

Precision Manufacturing Capability

For miniature and complex components.

Stable Production Management

For repeat orders and volume manufacturing.

Engineering Support

From drawing review to production optimization.

Integrated Manufacturing Solutions

Including:

  • CNC machining
  • Swiss CNC turning
  • Surface finishing
  • Quality inspection

YS Precision helps electronics companies transform precision component designs into reliable production parts.
